2422170000 - 8-Pole M8 Connection Plugs, RoHS Compliant, Pack of 25 (Pack of 25)

2422170000 - 8-Pole M8 Connection Plugs, RoHS Compliant, Pack of 25 (Pack of 25)

SKU: 2422170000   Download PDF

Select a Variant:
  • 2422170000 - 8-Pole M8 Connection Plugs, RoHS Compliant, Pack of 25 (Pack of 25)
Qty:
Now $152.79   Web pricing policy
BEFORE   $0.00 Now $152.79 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing our premium built-in plugs featuring an M8 connection with 8 poles, part number 2422170000 These plugs adhere to RoHS standards, with a specific exemption outlined Each order contains 25 units, making it ideal for bulk purchases.

Features and Benefits:

    •Compatible with M8 pin housings.

    •Protection degree rated at IP67.

    •Gold contact surface.

    •Rated for a nominal voltage of 30 V.

    •Rated current of 4 A for 3-, 4-, and 5-pole configurations.

    •Temperature range from -25 to 95 °C.

    •High durability with ≥ 100 plugging cycles.

Specifications:

 Number of poles 8
 Shield connection Yes
 Nominal current 1.5 A
 Rated voltage 60 V (3-pole) / 30 V (4-, 5-, and 8-pole)
 Housing main material LCP
 Tightening torque M8: 0.5 Nm
 Contact material Cu-alloy
 Lock nut material Nickel-plated CuZn
 Material of the flange-mounted housing Nickel-plated CuZn
 UL 94 flammability rating V-0
 Pollution severity 3 (2 within the sealed area)
