2424310000 - 4-Pole M12 Connector, IP67, 250V, Built-in Plugs (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the M12 connector, a reliable solution designed for versatility in various applications This compact connector features four poles and includes built-in plugs, providing a seamless integration Its M12 connection thread and front mounting design facilitate straightforward installation With a nominal current rating of 4 A and a voltage rating of 250 V, this connector is engineered for a wide range of electrical tasks.

It operates comfortably within a temperature range of -30 to 80 degrees Celsius and boasts an IP67 protection rating, ensuring performance in challenging environments For added durability, the housing is nickel-plated, and the Au (gold) contact surface enhances reliability in connectivity.

Features and Benefits:

•Nickel-plated housing for enhanced durability.

•IP67 protection ensuring resistance to dust and water.

•Front mounting type for ease of installation.

•Au (Gold) contact surface for reliable electrical connection.

•High insulation resistance of 100 MΩ.

Specifications:
