2422480000 - IP67 M12 Connector with 8 Poles, RoHS Compliant (Pack of 25)

2422480000 - IP67 M12 Connector with 8 Poles, RoHS Compliant (Pack of 25)

SKU: 2422480000   Download PDF

Select a Variant:
  • 2422480000 - IP67 M12 Connector with 8 Poles, RoHS Compliant (Pack of 25)
Qty:
Now $144.53   Web pricing policy
BEFORE   $0.00 Now $144.53 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Experience reliability with the SAID-M12B-8-9SMT connector, featuring a built-in design with eight poles that ensures strong performance across diverse environments Compliant with RoHS regulations, this sturdy M12 socket boasts an impressive IP67 protection rating, making it perfect for applications requiring both durability and adherence to strict standards Whether for industrial or other demanding settings, this connector guarantees a dependable connection you can count on.

Features and Benefits:

    •Built-in plugs.

    •A-coded coding.

    •Suitable for a temperature range of -25 to 95 °C.

    •IP67 protection degree.

    •High resistance to pollution severity rated at 3.

    •Gold contact surface.

    •Nickel-plated materials used for enhanced durability.

Specifications:

 Order No. 2422480000
 GTIN (EAN) 4050118431223
 Nominal voltage 30 V
 Rated voltage 250 V (4-pole) / 60 V (5-pole) / 30 V (8-pole)
 Nominal current 2 A
 Rated current 4 A (4- and 5-pole) / 2 A (8-pole)
 Shield connection No
 Plugging cycles ≥ 100
 Contact material Cu-alloy
 Housing main material LCP
 Lock nut material Nickel-plated CuZn
 Tightening torque M12: 0.8 Nm
 UL 94 flammability rating V-0
