2422350000 - M8 3-Pole Built-In Connector with M10 Thread (Pack of 25)

SKU: SKU: 2422350000 Download PDF

Variant:

2422350000 - M8 3-Pole Built-In Connector with M10 Thread (Pack of 25)

Now $178.71

~~BEFORE $0.00~~ Now $178.71

Sold out

Web pricing policy Shipping calculated at checkout.

IN STOCK

Shipping Available

Free shipping on orders above $1000.* Only on standard purchases of cables and wires.

View full details

Product Information Resources Reviews

Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a sophisticated built-in plug connector featuring an M8 configuration, equipped with a mounting thread of M10 and containing 3 poles This connector meets RoHS compliance and showcases various construction attributes and functionality Perfect for reliable and efficient connectivity in your projects.

Features and Benefits:

•Nickel-plated housing surface.

•Shield connection available.

•Front mounting type.

•Protection degree IP67.

•A high insulation resistance of 100 MΩ.

•Supports a temperature range of -30 to 80 °C.

•Can handle plugging cycles of at least 100.

Specifications:

Number of poles	3
Nominal voltage	60 V
Rated voltage	60 V (3-pole) / 30 V (4-, 5- and 8-pole)
Nominal current	4 A
Rated current	4 A (3-, 4- and 5-pole) / 1.5 A (8-pole)
Installation height	13 mm
Tightening torque	0.5 Nm
Mounting torque max	0.8 Nm
Contact material	Cu-alloy
Contact surface	Au (Gold)
Housing main material	CuZn
Seal material	FPM
Grouting material	PUR
Pollution severity	3 (2 within the sealed area)
