2422920000 - M8 PCB Connector with IP67 Rating, 3 Poles, M10 Thread (Pack of 25)

Description:

Introducing a reliable PCB plug-in connector designed for effortless front mounting This connector features built-in M8 plugs with a sturdy three-pole design, complemented by an M10 mounting thread The length of the connecting strand or cable is detailed in the general ordering information Crafted with a nickel-plated housing surface, it ensures both durability and resistance Capable of handling a nominal current of 4 A and a voltage rating reaching 60 V, this connector operates efficiently within a robust temperature range of -30 °C to +80 °C.

Additionally, it boasts an IP67 protection rating, guaranteeing exceptional reliability and durability in challenging conditions.

Features and Benefits:

•Nickel-plated housing surface.

•IP67 protection degree for high durability.

•THT/THR solder connection for PCB mounting.

•Suitable for front mounting.

•Supports a wide temperature range from -30 to 80 °C.

•Gold contact surface for enhanced conductivity.

Specifications:
