2530820000 - M12 L-Coded Connector, 5 Pole, IP67, 63V, 16A (Pack of 60)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a premium built-in plug, featuring an M12 connector designed with a mounting thread of M16 and equipped with 5 poles This connector is RoHS compliant, weighing in at just 1517 g It boasts an L-coded specification and is rated for a nominal voltage of 63 V and a nominal current of 16 A The rated current matches, assuring consistent performance With an IP67 protection rating when fully assembled, this connector offers exceptional reliability across various settings.

The contact surfaces are elegantly coated in gold over nickel, while the housing is constructed from durable PA material With the ability to withstand up to 500 plugging cycles, this connector is designed for lasting use.

Features and Benefits:

•RoHS compliant with exemption.

•Plugging cycles of 500 for enhanced longevity.

•IP67 protection degree when fully mounted.

Specifications:
