2423930000 - M12 Plug Connector with Nickel-Plated Housing, 4 Poles (Pack of 10)

2423930000 - M12 Plug Connector with Nickel-Plated Housing, 4 Poles (Pack of 10)

SKU: 2423930000   Download PDF

Select a Variant:
  • 2423930000 - M12 Plug Connector with Nickel-Plated Housing, 4 Poles (Pack of 10)
Qty:
Now $70.20   Web pricing policy
BEFORE   $0.00 Now $70.20 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the SAIE-M12BB-4-H10TL M12 built-in plug connector, designed with a robust M12 mounting thread and featuring 4 poles for versatile connectivity This connector has a weight of 178 grams and is crafted with a nickel-plated housing, making it resilient and suitable for various applications It meets RoHS compliance with an exemption code of 6c, ensuring it adheres to safety and environmental standards.

This reliable connector is your go-to solution for secure and efficient electrical connections in demanding environments.

Features and Benefits:

    •B-coded for specific usage.

    •IP67 protection degree for water and dust resistance.

    •Able to handle a nominal voltage of 250V and a nominal current of 4A.

    •Suitable for a temperature range of -30 to 80 °C.

    •Greater than or equal to 100 plugging cycles.

Specifications:

 Mounting thread M12
 Number of poles 4
 Nominal voltage 250 V
 Rated current 4 A
 Tightening torque 0.8 Nm
 Mounting torque max 1.2 Nm
 Insulation resistance 100 MΩ
 Pollution severity 3
 Contact surface Au (Gold)
 Contact material Cu-alloy
 Housing main material CuZn, nickel-plated
 Protection degree IP67
 Plugging cycles ≥ 100
 Installation height 10 mm
