2422770000 - M8 Waterproof Connector with IP67 Rating and M10 Mounting Thread (Pack of 25)

Description:

Introducing the M8 plug-in connector, a feature-rich component designed for versatility This connector boasts built-in plugs with a robust M10 mounting thread and includes 8 poles for reliable connectivity With the order number 2422770000, its nickel-plated housing guarantees durability and resistance to corrosion Compliant with RoHS standards, this connector adapts seamlessly to various environmental conditions.

It is intended for rear panel mounting and operates efficiently across a temperature range of -30 to 80 °C The nominal voltage reaches 30 V, while it supports a rated current of up to 4 A Additionally, with an IP67 rating, this device provides excellent protection against water and dust, making it a dependable choice for demanding applications.

Features and Benefits:

•Built-in plugs.

•Nickel-plated housing for durability.

•Can operate in a wide temperature range.

•Supports shield connection.

•Rear panel mounting type.

•IP67 protection degree.

Specifications:
