2422680000 - IP67 M8 Connector with Nickel-Plated Housing and 5 Poles (Pack of 25)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SAIE-M8B-5-F13SMT connector, expertly crafted for reliable M8 connections This component boasts built-in plugs and features a robust M10 mounting thread with a configuration of 5 poles Weighing in at just 744 grams, it meets RoHS standards, ensuring environmental compliance The connector is designed for front mounting and comes with a durable nickel-plated housing, providing both strength and corrosion resistance.

It handles a nominal voltage of 30 V, accommodating up to 60 V for 3-pole setups, while 4-, 5-, and 8-pole connections are rated for 30 V Current ratings include 4 A for 3-, 4-, and 5-pole configurations, and 15 A for 8-pole connections Operating across a temperature spectrum of -30 to 80 °C, this connector maintains performance in a variety of environments With an IP67 protection rating, it safeguards against dust and water ingress.

Additionally, the gold-plated contact surface enhances conductivity and overall reliability, making it a versatile choice for various applications The M8 connection thread ensures compatibility across different systems.

Features and Benefits:

•Nickel-plated housing surface.

•Compliant with RoHS regulations.

•Front mounting design.

•Gold contact surface for increased reliability.

•Usage in a wide temperature range of -30 to 80 °C.

•Protection degree of IP67.

•More than 100 plugging cycles.

Specifications:
