2424130000 - M8 5-Pole PCB Connector, IP67, RoHS Compliant (Pack of 25)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SAID-M8B-8-THR PCB plug-in connector, engineered with impressive functionality and reliability This connector features an integrated 5-pole configuration and incorporates a B-coded system for seamless connections Housed in an M8 socket design, it adheres to RoHS standards, ensuring environmental compliance and exemption concerning lead content Available in packs of 25, this connector boasts a robust LCP housing and M8 connection thread.

It supports a nominal voltage of 30 V, with rated voltages varying from 60 V for 3-pole setups to 30 V for 4-, 5-, and 8-pole options Designed for efficient performance, both the nominal and rated current are rated at 4 A, while the operational temperature range spans from -25 to 95 °C Offering IP67 protection, this connector is built to withstand various environmental challenges It features a gold-plated contact surface crafted from a durable copper alloy, ensuring maximum reliability over time.

With a lifespan of at least 100 plugging cycles, the SAID-M8B-8-THR is the perfect choice for applications demanding longevity and performance.

Features and Benefits:

•Built-in plugs with 5-pole configuration..

•B-coded for easy identification..

•Designed for an M8 socket housing..

•Gold contact surface for better conductivity..

•High protection degree of IP67..

Specifications:
