2422970000 - M12 Connector, IP67 Rated, 4-Pole, 250V, Built-in Plugs (Pack of 10)

Description:

Introducing our innovative built-in connector equipped with M12 plugs, designed for efficient connectivity It features a mounting thread size of M12 and incorporates four poles for versatile applications The connector assembly comes with a specified cable length and a lightweight design, weighing only 10912 grams This product adheres to RoHS standards and has a specific exemption, ensuring compliance with REACH SVHC regulations concerning lead.

With a voltage rating of 250V (both nominal and maximum) and a capacity for a nominal current of 4A, it is engineered to perform reliably across a temperature spectrum from -30 to 80 degrees Celsius Built to withstand challenging conditions, it boasts an IP67 protection rating, guaranteeing it is both dust-tight and capable of withstanding water immersion The robust construction features a nickel-plated housing and a gold contact surface, ensuring a reliable connection.

Additionally, its solid M12 connection thread offers features for effective shield connection and a front mounting structure, making it a dependable choice for your connectivity needs.

Features and Benefits:

•Compliant with RoHS regulations.

•Designed for efficient electrical connections with a protection rating of IP67.

•Built-in with four poles for versatility in connections.

•Nickel-plated housing and gold contact surface for improved durability and conductivity.

Specifications:
