Belden 8700 28 AWG 1 Conductor Solid Tinned Copper 300V Special Audio Cable

Description:

Miniature, 28 AWG solid 0.013" tinned copper conductor, polypropylene insulation, bare copper braid shield (90% coverage), PVC jacket.

Insulation:

• Material: PP - Polypropylene
• Nom. Insulation Diameter: 0.023 in (0.58 mm)

Outer Shield:

• Shield Type: Braid
• Material: Bare Copper (BC)
• Coverage: 92%

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Diameter: 0.054 in (1.4 mm)
• Overall Cable Diameter (Nominal): 0.054 in (1.4 mm)

Standards:

• Voltage Rating: 300 V RMS
• Operating Temperature: -30°C To +105°C
• Nom. Characteristic Impedance: 32 Ohm

Applications:

• Analog audio, Instrumentation

Specifications:

• Size (AWG): 28
• No. of Conductor: 1
• Stranding: Solid
• Nom. Diameter: 0.013 in
• Conductor Material: TC - Tinned Copper
• Part Number: 8700
