2424190000 - M8 8-Pole Plug with Mounting Thread, 30V/60V Rated (Pack of 25)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing this versatile product with a built-in M8 connector equipped with a mounting thread and designed with 8 poles Weighing just 2 grams, this component adheres to several directives including RoHS, ensuring safe usage It operates at a nominal voltage of 30 V, supporting a maximum of 60 V for three poles Current ratings are adjustable with 4 A available for configurations of 3, 4, and 5 poles, while 8 poles are rated at 1.

5 A Enjoy reliable performance and quality with this compact and efficient item.

Features and Benefits:

•Compliant with RoHS exemption 6c.

•The temperature operating range is between -25 and 95 °C.

•Achieves IP67 protection degree.

•Utilizes gold-plated contacts to enhance conductivity.

•Can withstand a minimum of 100 plugging cycles.

Specifications:
