2423500000 - IP67 4-Pole M12 Connector, Gold Contacts, -25 to 95 °C (Pack of 25)

SKU: SKU: 2423500000 Download PDF

Select a Variant:

2423500000 - IP67 4-Pole M12 Connector, Gold Contacts, -25 to 95 °C (Pack of 25)

SET THE QTY:

Now $92.68 Web pricing policy

~~BEFORE $0.00~~ Now $92.68 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Introducing the SAID-M12S-4S-9SMT connector, a robust solution featuring four poles and integrated plugs tailored for M12 applications Weighing only 27 grams, this connector operates efficiently within a temperature range of -25 to 95 °C With a durable construction from LCP material and a gold contact surface, it provides reliable conductivity It boasts an impressive IP67 rating for protection against dust and water ingress and can withstand at least 100 plugging cycles.

Designed for 4-pole configurations, this connector supports a rated voltage of 250 V and a nominal current of 4 A, making it a reliable choice for your connectivity needs.

Features and Benefits:

•A-coded for compatibility.

•Shield connection included.

•Rated voltage of 250 V.

•Temperature range from -25 to 95 °C.

•High degree of protection with IP67.

•Constructed from durable LCP material.

•Equipped with gold contact surface.

•4 poles for effective connectivity.

•Supports a minimum of 100 plugging cycles.

Specifications:

Nominal voltage	250 V
Rated current	4 A
Protection degree	IP67
Contact material	Cu-alloy
Lock nut material	Nickel-plated CuZn
Plugging cycles	≥ 100
Pollution severity	3 (2 within the sealed area)
Connection thread	M12
Tightening torque	M12: 0.8 Nm
Number of poles	4
UL 94 flammability rating	V-0
Contact surface	Au (Gold)
Housings	M12 pin
