2423070000 - M8 PCB Connector with 4 Poles, IP67 Rating, 9mm Height (Pack of 25)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing this advanced PCB plug-in connector featuring integrated M8 plugs This connector is crafted with a mounting thread of M10 and includes 4 poles for efficient connectivity Its nickel-plated finish ensures durability and compliance with RoHS regulations With a compact height of 9 mm, it supports a rated voltage of 60V for 3 poles and 30V for configurations with 4, 5, and 8 poles Designed to operate within a wide temperature range of -30°C to 80°C, it also boasts an impressive IP67 protection rating, making it suitable for challenging environments.

This connector allows for front mounting and comes equipped with gold contacts, providing an insulation resistance of 100 MΩ and the ability to withstand a minimum of 100 plugging cycles, ensuring long-lasting performance for your applications.

Features and Benefits:

•Compliant with RoHS exemption.

•Nickel-plated housing surface.

•Front mounting type.

•Protection degree of IP67.

•Insulation resistance of 100 MΩ.

•THT/THR solder connection.

•Durable contact material of Cu-alloy with gold surface.

Specifications:
