2424210000 - IP67 M12 5-Pole Connector with M 16 x 1.5 Thread (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Explore the versatility of this PCB plug-in connector, expertly engineered for reliable M12 connections It features a robust M 16 x 15 mounting thread and comprises five poles for efficient connectivity Meeting RoHS compliance, this connector also boasts an impressive IP67 protection rating, ensuring it is well-suited for harsh environments where reliability and adherence to regulations are essential.

Features and Benefits:

•Rear panel mounting type.

•Nickel-plated housing surface.

•A-coded connection.

•Rated for nominal voltage of 60 V and nominal current of 4 A.

•Insulation resistance of 100 MΩ.

•Suitable for a temperature range of -30 to 80 °C.

•≥ 100 plugging cycles.

•Lock nut material is nickel-plated CuZn.

Specifications:
