2422070000 - M12 Built-In Plug Connector, 8 Poles, PG 9 Thread (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the M12 built-in plug connector, designed for robust industrial applications This connector features a PG 9 mounting thread and accommodates eight poles while adhering to RoHS compliance standards Weighing in at just 20 grams, it offers impressive electrical performance with a rated voltage of up to 250 volts for 4-pole configurations and 60 volts for 5-pole setups, alongside a nominal voltage of 30 volts.

Engineered to perform in a wide temperature range from -30°C to 80°C, this connector guarantees dependable operation even in challenging environments.

Features and Benefits:

•A-coded housing.

•M12 socket design.

•IP67 protection degree for enhanced durability.

•Rear panel mounting type.

•Connector made from nickel-plated CuZn material.

•Gold contact surface for improved conductivity.

•Insulation resistance of 100 MΩ.

•Good pollution severity rating.

•Can withstand more than 100 plugging cycles.

Specifications:
