2422140000 - M8 Connector with 8 Poles, RoHS, -25 to 95°C Range (Pack of 25)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SAID-M8B-8S-SMT connectors, designed with built-in plugs housed within a robust M8 casing featuring 8 poles These connectors operate efficiently in temperatures ranging from -25 to 95 °C and meet RoHS compliance, including specific exemptions With a rated voltage of 60V for 3-pole configurations and 30V for those with 4, 5, and 8 poles, they are versatile for various applications Constructed from LCP material and featuring a nickel-plated housing, these connectors promise stability and reliability in numerous environments.

Features and Benefits:

•IP67 protection degree.

•Plugging cycles rated at ≥ 100.

•Nominal current capacity of 1.5 A.

•Strand/cable length unspecified.

•Compatible with a variety of environmental conditions.

Specifications:
