8876440100 - 10m SC Duplex Dragline Cable, PUR, IP 20 Rated

8876440100 - 10m SC Duplex Dragline Cable, PUR, IP 20 Rated

SKU: 8876440100   Download PDF

Select a Variant:
  • 8876440100 - 10m SC Duplex Dragline Cable, PUR, IP 20 Rated
Qty:
Now $100.35   Web pricing policy
BEFORE   $0.00 Now $100.35 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the IE-FM6D2UE0010MSD0SD0X dragline cable, expertly engineered for enhanced connectivity Featuring robust SC duplex connectors and an IP 20 rating, this cable is built to perform With a fiber core diameter of 625 µm and constructed from durable PUR material, it spans a length of 10 meters This product meets RoHS compliance standards, ensuring it aligns with essential regulations Its exceptional temperature resilience allows it to operate efficiently in environments ranging from -40 °C to 80 °C, making it an ideal choice for high-performance data transmission.

Features and Benefits:

    •Compliant with RoHS and REACH regulations.

    •Rated for extreme temperature conditions.

    •Robust bending capabilities with a minimum bending radius.

    •Designed with break-out dragline structure.

Specifications:

 Length 10 m
 Fibre type GOF Multimode OM1
 Core diameter 62.5 µm
 Sheath diameter 6 mm
 Insertion loss ≤ 0.4 dB
 Return loss (attenuation) ≥ 30 dB
 Attenuation 2.7 dB/km at 850 nm, ≤ 0.5 dB/km at 1300 nm
 Bandwidth 200 MHz*km at 850 nm, 500 MHz*km at 1300 nm
 Bending cycles 100,000
 Min. bending radius, once only 25 mm
 Min. bending radius, repetitive 77 mm
 Environmental Compliance Compliant with exemption
 Connector standard IEC 61754-4
