8876431300 - 50µm x 130m OM2 Dragline Cable with PUR Sheath

8876431300 - 50µm x 130m OM2 Dragline Cable with PUR Sheath

SKU: 8876431300   Download PDF

Select a Variant:
  • 8876431300 - 50µm x 130m OM2 Dragline Cable with PUR Sheath
Qty:
Now $751.84   Web pricing policy
BEFORE   $0.00 Now $751.84 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing an exceptional dragline cable, specifically crafted for SC duplex connections and compliant with IP 20 standards This robust cable features a multimode OM2 fiber type, with a core diameter of 50 µm, and extends to an impressive length of 130 meters Encased in a durable PUR sheath, it is expertly designed for break-out dragline applications Additionally, it adheres to important environmental compliance standards, including RoHS and REACH, ensuring safety and sustainability in your projects.

Features and Benefits:

    •Compliant with RoHS exemption.

    •Supports up to 100,000 bending cycles.

    •Bending radius of 25 mm for once only and 77 mm for repetitive use.

    •Sheath material is PUR.

    •Plug type SC-Duplex, IP20, with straight male contacts.

Specifications:

 Length 130 m
 Length (inches) 5,118.11 inch
 Storage temperature -40 °C to 80 °C
 Operating temperature -40 °C to 80 °C
 Installation temperature -20 °C to 60 °C
 Attenuation 2.3 dB/km at 850 nm, ≤ 0.5 dB/km at 1300 nm
 Bandwidth 500 MHz*km at 850 nm, 500 MHz*km at 1300 nm
 Insertion loss ≤ 0.4 dB
 Return loss (attenuation) ≥ 30 dB
 Core diameter 50 µm
 Sheath diameter 6 mm
 Halogen No
