2860910100 - 10m RJ12 Cat.3 Patch Cable with LSZH Sheath

2860910100 - 10m RJ12 Cat.3 Patch Cable with LSZH Sheath

SKU: 2860910100   Download PDF

Select a Variant:
  • 2860910100 - 10m RJ12 Cat.3 Patch Cable with LSZH Sheath
Qty:
Now $52.31   Web pricing policy
BEFORE   $0.00 Now $52.31 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Ensure reliable connectivity with this 10-meter patch cable equipped with RJ12 connectors, designed to meet Cat3 specifications It boasts a low smoke zero halogen (LSZH) sheath for enhanced fire safety Built to perform in a temperature range of -20 °C to 60 °C, this cable complies with RoHS standards, containing no Substances of Very High Concern (SVHC) in amounts exceeding 01 percent by weight Perfect for secure and efficient networking solutions.

Features and Benefits:

    •Operating temperature range of -20 °C to 60 °C.

    •Available in a length of 10 meters.

    •Low smoke zero halogen (LSZH) sheath.

    •Compliant with RoHS regulations.

    •Shielding type U/UTP.

    •Insulation resistance greater than or equal to 100 MΩ.

    •Rated impulse withstand voltage of 6 kV.

    •Plug type RJ12, IP20, male contact, straight, unshielded.

    •Application-specific communication cable facilities.

Specifications:

 Cable Category Cat.3
 Sheath Diameter 4.8 mm
 Max Sheath Diameter 4.95 mm
 Min Sheath Diameter 4.65 mm
 Insulation Voltage (max) 500 V
 Operating Voltage 50 V
 Number of Wires 6
 Connector Standard TIA-1096-A
 Resistance to Flame Spread in accordance with IEC 60332-1
