2860910011 - 1.1m RJ12 Patch Cable, Cat.3, LSZH Insulation

SKU: SKU: 2860910011 Download PDF

Select a Variant:

2860910011 - 1.1m RJ12 Patch Cable, Cat.3, LSZH Insulation

SET THE QTY:

Now $12.51 Web pricing policy

~~BEFORE $0.00~~ Now $12.51 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Experience reliable connectivity with this 11-meter patch cable, featuring RJ12 connectors and built to meet Cat3 standards Crafted from LSZH material, this cable complies with RoHS regulations and adheres to VDE 0603-100 standards thanks to its double insulation structure It boasts a cross-section of 3x2xAWG 24/7 and an impressive insulation resistance of 100 MΩ or more With a voltage rating of up to 500 V and a nominal current capacity of 1 A, it is suitable for a variety of applications.

This cable operates efficiently within a temperature range of -20 °C to 60 °C, making it versatile for different environments.

Features and Benefits:

•Compliant with RoHS regulations.

•Double insulation for enhanced safety.

•Low smoke zero halogen (LSZH) material.

•Designed for specific communication applications.

Specifications:

Cable Structure	Double insulation according to VDE 0603-100
Length	1.1 m
Sheath Diameter	4.8 mm
Nominal Current	1 A
Operating Voltage	50 V
Rated Impulse Withstand Voltage	6 kV
Signal Propagation Time	5.45 ns/m
Connector Standard	TIA-1096-A
Category	Cat.3
Insulation	PE
Insulation Cross-section	1 mm
Material Sheath	LSZH
Number of Wires	6
Insulation Resistance	≥ 100 MΩ
Environmental Compliance Status	Compliant without exemption
Sheathing Colour	red
Flame Spread Resistance	in accordance with IEC 60332-1
Plug Type	RJ12, IP20, male contact, straight, unshielded
