2779110000 - 10 Gbps Multimode SFP+ Transceiver, LC-Duplex, 0.3 km
2779110000 - 10 Gbps Multimode SFP+ Transceiver, LC-Duplex, 0.3 km
SKU: SKU: 2779110000 Download PDF
- 2779110000 - 10 Gbps Multimode SFP+ Transceiver, LC-Duplex, 0.3 km
- 2779110000 - 10 Gbps Multimode SFP+ Transceiver, LC-Duplex, 0.3 km
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Experience high-speed connectivity with this SFP+ transceiver, capable of delivering data rates up to 10 Gbps Designed for multimode applications, it is equipped with an LC-Duplex connector and supports transmission distances of up to 03 kilometers This reliable device operates efficiently in a wide temperature range from -40 °C to 85 °C, making it suitable for various environments Moreover, it adheres to RoHS compliance standards, ensuring it is free from any exemptions.
Features and Benefits:
•Digital diagnostic monitor function (DDM) supported.
•Compliant with RoHS without exemptions.
Specifications:
| Transmission rate | 10 Gbps |
| Connector type | LC-Duplex |
| Transmission distance, typ. | 0.3 km |
| Wavelength TX min. | 840 nm |
| Wavelength TX max. | 860 nm |
| Wavelength RX min. | 840 nm |
| Wavelength RX max. | 860 nm |
| Receive power min. | -9.9 dBm |
| Receive power max. | -1 dBm |
| Transmission power min. | -6.5 dBm |
| Transmission power max. | -1 dBm |
| Link-budget | 3.4 dB |
| Supply voltage | 3.3 V (via Ethernet switch) |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -40 °C...85 °C |
