Description:
Introducing the IE-SFP-1GE-SM-20-BIDI-TX1550, a high-performance singlemode BiDi SFP transceiver that delivers impressive data transmission speeds of 1000 Mbps Capable of operating over distances of up to 20 kilometers, it functions effectively in a wide temperature spectrum from -40 °C to 85 °C This transceiver meets RoHS compliance and has undergone rigorous testing to ensure EMC conformity based on EN 55032 and EN 55035 standards.
For optimal functionality, it is designed to be used in pairs and includes a digital diagnostic monitoring feature for enhanced performance tracking.
Features and Benefits:
•Supports data transmission rate of 1000 Mbps.
•Singlemode BiDi transceiver design.
•Compatible with LC-Simplex connectors.
•Digital diagnostic monitor function (DDM) supported.
•Must be used in pairs for optimal performance.
Specifications:
| Storage temperature | -40 °C to 85 °C |
| Operating temperature | -40 °C to 85 °C |
| Humidity | 5 to 95 % (non-condensing) |
| Transmission distance | 20 km |
| TX wavelength | 1,550 nm |
| RX wavelength | 1,310 nm |
| Receive power min | -23 dBm |
| Receive power max | -3 dBm |
| Transmission power min | -8 dBm |
| Transmission power max | -2 dBm |
| Link-budget | 15 dB |
| Supply voltage | 3.3 V |
| Type of mounting | Insert in SFP slot |
