2682520000 - BiDi SFP Transceiver 1000 Mbps, 10 km Range
2682520000 - BiDi SFP Transceiver 1000 Mbps, 10 km Range
SKU: SKU: 2682520000 Download PDF
- 2682520000 - BiDi SFP Transceiver 1000 Mbps, 10 km Range
- 2682520000 - BiDi SFP Transceiver 1000 Mbps, 10 km Range
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Experience seamless connectivity with our SFP transceiver, designed to transmit data at a speed of 1000 Mbps using innovative singlemode BiDi technology Featuring LC-Simplex connectors, this device boasts an impressive range of up to 10 km, making it perfect for various networking needs It operates efficiently in temperatures ranging from -40 °C to 85 °C and adheres to RoHS standards without any exceptions.
Additionally, the transceiver includes digital diagnostic monitoring and functions optimally in humidity conditions of 5% to 95% (non-condensing), ensuring reliable performance in diverse environments.
Features and Benefits:
•Transmission distance of 10 km.
•Digital diagnostics monitoring (DDM) supported.
•Power supply operates at 3.3 V via Ethernet switch.
•Utilizes BiDi technology which requires pairing with another compatible transceiver.
Specifications:
| Order No. | 2682520000 |
| Transmission rate | 1000 Mbps |
| Connector type | LC-Simplex |
| Wavelength TX typ. | 1,310 nm |
| Wavelength RX typ. | 1,550 nm |
| Receive power min. | -20 dBm |
| Receive power max. | -3 dBm |
| Transmission power min. | -9 dBm |
| Transmission power max. | -3 dBm |
| Link-budget | 11 dB |
| Type of mounting | Insert in SFP slot |
| Storage temperature | -40 °C to 85 °C |
| Operating temperature | -40 °C to 85 °C |
| Humidity | 5 to 95 % (non-condensing) |
