2682510000 - 1000 Mbps Singlemode SFP Transceiver, 40 km Range
2682510000 - 1000 Mbps Singlemode SFP Transceiver, 40 km Range
SKU: SKU: 2682510000 Download PDF
- 2682510000 - 1000 Mbps Singlemode SFP Transceiver, 40 km Range
- 2682510000 - 1000 Mbps Singlemode SFP Transceiver, 40 km Range
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Elevate your data transmission capabilities with this advanced SFP transceiver, engineered for seamless communication at speeds of 1000 Mbps using singlemode technology Equipped with an LC-Duplex connector, this transceiver supports impressive distances of up to 40 km With a robust temperature operating range from -40 °C to 85 °C, it is built to perform reliably across diverse environments, making it an excellent choice for various networking applications.
Features and Benefits:
•Compliant with RoHS standards without exemptions.
•Digital diagnostic monitor function (DDM) supported.
•Operating temperature range from -40 °C to 85 °C.
•Humidity tolerance from 5 to 95% (non-condensing).
Specifications:
| Transmission rate | 1000 Mbps |
| Connector type | LC-Duplex |
| Transmission distance | 40 km |
| Supply voltage | 3.3 V (via Ethernet switch) |
| Operating temperature, max. | 85 °C |
| Operating temperature, min. | -40 °C |
| Receive power, min. | -24 dBm |
| Receive power, max. | -3 dBm |
| Transmission power, min. | -3 dBm |
| Transmission power, max. | 3 dBm |
| Link-budget | 21 dB |
| Storage temperature, max. | 85 °C |
| Storage temperature, min. | -40 °C |
| EMC standards | EN 55032, EN 55035 |
| Safety standard | UL 62368-1 |
