2682490000 - 1000 Mbps SFP Transceiver, LC-Duplex, 2 km Range
2682490000 - 1000 Mbps SFP Transceiver, LC-Duplex, 2 km Range
SKU: SKU: 2682490000 Download PDF
- 2682490000 - 1000 Mbps SFP Transceiver, LC-Duplex, 2 km Range
- 2682490000 - 1000 Mbps SFP Transceiver, LC-Duplex, 2 km Range
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Experience reliable connectivity with the SFP Transceiver, which delivers a transmission speed of 1000 Mbps Ideal for multimode applications, it features an LC-Duplex connector and can transmit data effectively over distances of up to 2 kilometers Built to withstand extreme conditions, this transceiver operates efficiently within a temperature range of -40 °C to 85 °C With a weight of just 18 grams, it meets various environmental standards, including RoHS, making it a great choice for eco-conscious users.
Features and Benefits:
•Supports Digital diagnostic monitor function (DDM).
•Operates with a supply voltage of 3.3 V via Ethernet switch.
•Compliant with RoHS and REACH regulations.
Specifications:
| Transmission rate | 1000 Mbps |
| Transceiver type | Multimode |
| Connector type | LC-Duplex |
| Transmission distance, typ. | 2 km |
| Wavelength TX min. | 1,270 nm |
| Wavelength TX max. | 1,355 nm |
| Wavelength RX min. | 1,260 nm |
| Wavelength RX max. | 1,620 nm |
| Receive power min. | -19 dBm |
| Receive power max. | -1 dBm |
| Transmission power min. | -9 dBm |
| Transmission power max. | -1 dBm |
| Link-budget | 10 dB |
| Storage temperature | -40 °C to 85 °C |
| Operating temperature | -40 °C to 85 °C |
| Humidity | 5 to 95 % (non-condensing) |
| Type of mounting | Insert in SFP slot |
