2682470000 - 100Mbps SFP Transceiver, 60km Range, LC-Duplex Connection
2682470000 - 100Mbps SFP Transceiver, 60km Range, LC-Duplex Connection
SKU: SKU: 2682470000 Download PDF
- 2682470000 - 100Mbps SFP Transceiver, 60km Range, LC-Duplex Connection
- 2682470000 - 100Mbps SFP Transceiver, 60km Range, LC-Duplex Connection
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the SFP Transceiver, expertly crafted for efficient data transmission at 100 Mbps over singlemode fiber optic connections with LC-Duplex connectors It boasts an impressive range of up to 60 km and operates seamlessly across a temperature spectrum from -40 °C to 85 °C This device is RoHS compliant and free from SVHC chemicals, ensuring safety in its application With a built-in digital diagnostic monitoring function, it excels in diverse environments, including those with high humidity levels of up to 95%.
The transceiver is backed by a 3-year performance guarantee, ensuring reliability for your connectivity needs.
Features and Benefits:
•Supports digital diagnostic monitor function (DDM).
•ADhering to EMC standards EN 55032 and EN 55035.
•Compatible with safety standard UL 62368-1.
•Designed with a link-budget of 29 dB.
Specifications:
| Transmission rate | 100 Mbps |
| Transceiver type | Singlemode |
| Connector type | LC-Duplex |
| Transmission distance, typ. | 60 km |
| Wavelength (TX) | 1,280 nm - 1,340 nm |
| Wavelength (RX) | 1,260 nm - 1,620 nm |
| Receive power | -34 dBm - -3 dBm |
| Transmission power | -5 dBm - 0 dBm |
| Storage temperature | -40 °C to 85 °C |
| Operating temperature | -40 °C to 85 °C |
| Humidity | 5 to 95 % (non-condensing) |
| Supply voltage | 3.3 V (via Ethernet switch) |
| Type of mounting | Insert in SFP slot |
