2682450000 - 100 Mbps LC-Duplex SFP Transceiver, 4km Multimode Range
2682450000 - 100 Mbps LC-Duplex SFP Transceiver, 4km Multimode Range
SKU: SKU: 2682450000 Download PDF
- 2682450000 - 100 Mbps LC-Duplex SFP Transceiver, 4km Multimode Range
- 2682450000 - 100 Mbps LC-Duplex SFP Transceiver, 4km Multimode Range
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the SFP Transceiver, engineered for efficient data transmission at a speed of 100 Mbps This versatile device features a multimode capability and an LC-Duplex connector, allowing for seamless communication across distances up to 4 kilometers Built to withstand harsh conditions, it operates reliably within a temperature range of -40 °C to 85 °C Compliant with RoHS regulations, this transceiver also adheres to multiple EMC standards, including EN 55032 and EN 55035, and meets safety requirements outlined in UL 62368-1.
The device is equipped with digital diagnostic monitoring for enhanced performance tracking.
Features and Benefits:
•Supports temperatures from -40 °C to 85 °C.
•Digital diagnostic monitor function (DDM) supported.
•Environmentally compliant with RoHS.
•Emissions compliant with EN 55032 and EN 55035.
•Safety compliant with UL 62368-1.
Specifications:
| Transmission rate | 100 Mbps |
| Transceiver type | Multimode |
| Connector type | LC-Duplex |
| Transmission distance, typical | 4 km |
| Wavelength (TX) min | 1,270 nm |
| Wavelength (TX) max | 1,380 nm |
| Wavelength (RX) min | 1,260 nm |
| Wavelength (RX) max | 1,620 nm |
| Receive power min | -32 dBm |
| Receive power max | -3 dBm |
| Transmission power min | -20 dBm |
| Transmission power max | -14 dBm |
| Link-budget | 12 dB |
| Supply voltage | 3.3 V (via Ethernet switch) |
| Type of mounting | Insert in SFP slot |
| Storage temperature | -40 °C to 85 °C |
| Operating temperature | -40 °C to 85 °C |
| Humidity | 5 to 95 % (non-condensing) |
