Description:
Experience seamless connectivity with this unmanaged network switch, featuring 8 RJ45 ports that support Fast Ethernet speeds Engineered for durability, it boasts an IP30 rating and can function effectively in temperatures ranging from -40 °C to 75 °C This switch meets RoHS compliance and holds multiple safety and EMC certifications, guaranteeing reliable operation in diverse environments.
Features and Benefits:
•Operating altitude capable up to 6,000 m.
•Power and port LED indicators.
•Supports 10/100BaseT(X) connections with auto-negotiation.
•DIN rail mountable design.
•Metal housing with IP30 protection.
Specifications:
| Number of ports | 8x RJ45 |
| Storage temperature | -40 °C to 85 °C |
| Operating temperature | -40 °C to 75 °C |
| MTBF | 1,390,019 hours |
| Power supply | 12/24/48 V DC, 24 V AC |
| Current consumption | 0.14 A |
| Housing main material | Metal |
| Protection degree | IP30 |
| Bandwidth backplane | 1.6 Gbit/s |
| MAC table size | 1 K |
| Packet buffer size | 448 kBit |
| Safety standards | UL 61010-1, UL 61010-2-201 |
| Flow control | IEEE 802.3x flow control |
| Technology | Data switching, Store and Forward |
