2531060000 - Type H Socket Connector, IP20, 16A, ROHS Compliant

2531060000 - Type H Socket Connector, IP20, 16A, ROHS Compliant

SKU: 2531060000   Download PDF

Select a Variant:
  • 2531060000 - Type H Socket Connector, IP20, 16A, ROHS Compliant
Qty:
Now $18.91   Web pricing policy
BEFORE   $0.00 Now $18.91 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the FrontCom Insert Power large, Type H socket connector, crafted to meet ROHS compliance standards This versatile connector is designed for use with flexible conductors featuring wire end ferrules, accommodating conductor cross-sections up to 15 mm² It operates efficiently within a temperature range of -5 °C to 40 °C and possesses an IP20 protection rating With a nominal current capacity of 16 A and a rated voltage of 250 V, this connector is ideal for a variety of applications.

Features and Benefits:

    •Compliant under RoHS without exemption.

    •Protection degree of IP20.

    •Allows flexible and rigid conductor connections with specified cross-section.

    •Screw connection type.

Specifications:

 Operating temperature -5 °C...40 °C
 Clampable conductors 1.5 ... 2.5 mm² for rigid connection; 1.5 ... 1.5 mm² for flexible connection with wire end ferrule
 Stripping length 11 mm
 Housing main material PP
 Nominal current 16 A
 Rated voltage (AC) 250 V
 ETIM Classification EC001121
 ECLASS Classification 27-44-03-90
