2421690000 - M8 8-Pole Connector with IP67 Protection and Built-in Plugs (Pack of 10)

Description:

Introducing the SAIE-M8S-8-H55TL connector, expertly engineered with eight poles and an integrated plug design It features an M8 mounting thread, making installation straightforward This connector operates at a nominal voltage of 30 V and accommodates a rated voltage of 60 V for three-pole configurations, while supporting 30 V for four-, five-, and eight-pole setups Crafted for rear panel mounting, it ensures a strong seal with an IP67 rating, making it versatile for various environments.

Additionally, this connector is RoHS compliant and constructed from nickel-plated materials, guaranteeing quality and reliability for your applications.

Features and Benefits:

•Compliant with RoHS.

•IP67 protection degree.

•Suitable for rear panel mounting.

•Features a nominal current of 1.5 A.

•Can withstand a temperature range of -30 to 80 °C.

•Contact surfaces are gold-plated.

•Designed for ≥ 100 plugging cycles.

•Insulation resistance rated at 100 MΩ.

•Used in environments requiring robust connections with protection against dust and water.

Specifications:
