Product Information

Description:

Introducing the SAIE-M8B-8-H55TL, a robust M8 built-in connector with an M12 mounting thread and capacity for 8 poles Weighing just 1095 grams, this connector meets RoHS standards with specific exemptions and is ideal for a wide range of electronic uses With an operating temperature range of -30 to 80 °C, it is engineered for versatility and endurance Additionally, the connector is rated IP67 for exceptional protection against dust and water, making it a reliable choice for demanding environments.

Features and Benefits:

•Complies with RoHS with exemption 6c.

•Designed for M8 connections.

•Rear panel mounting type.

•IP67 protection degree.

•Made of nickel-plated CuZn housing.

•Gold-plated contact surface.

•Insulation resistance of 100 MΩ.

•Can endure ≥ 100 plugging cycles.

Specifications:

Installation height	5.5 mm
Mounting thread	M12
Nominal voltage	30 V
Rated voltage	60 V (3-pole) / 30 V (4-, 5- and 8-pole)
Nominal current	1.5 A
Rated current	4 A (3-, 4- and 5-pole) / 1.5 A (8-pole)
Temperature range	-30…80 °C
Shield connection	No
Contact material	Cu-alloy
Seal material	FPM
Lock nut material	Nickel-plated CuZn
Grouting material	PUR
Tightening torque	0.5 Nm
Mounting torque max	1.2 Nm
Pollution severity	3 (2 within the sealed area)
