2421620000 - M12 PCB Connector 5-Pole with M16 Thread, 5.5mm Height (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a versatile PCB plug-in connector, expertly crafted for M12 connectivity This reliable connector features a mounting thread of M 16 x 15 and is equipped with five poles With a compact installation height of just 55 mm, it seamlessly integrates into various applications Plus, it adheres to RoHS compliance regulations, ensuring safe usage while accommodating specific exemptions as necessary.

Features and Benefits:

•A-coded design for coding.

•Rear panel mounting type.

•IP67 protection degree.

•Gold contact surface.

•Nickel-plated CuZn housing.

•Rated for 4 A nominal current.

•Operating temperature range from -30 to 80 °C.

•Insulation resistance of 100 MΩ.

•More than 100 plugging cycles.

•Tightening torque specification of M12: 0.8 Nm.

•Maximum mounting torque at 1.2 Nm.

Specifications:
