2003370000 - Unshielded FrontCom Insert Plate, 23mm Height, Grey Housing

Description:

Introducing a versatile unshielded insert plate, specially crafted for compatibility with FrontCom systems Measuring 23 mm in height, 1165 mm in width, and 905 mm in length, this insert plate has a total net weight of 14178 g It comes equipped with a variety of inserts, including a fuse insert, pre-assembled data modules, and signal inserts, making it highly functional Built to perform within a temperature range of -35 °C to 66 °C, this product also adheres to RoHS regulations without any exemptions.

Its electrical connections support conductors ranging from 15 mm² to 25 mm², while rigid connections accommodate larger conductors up to 4 mm² Designed with user convenience in mind, it features a screw connection type and comes in a sleek grey housing Additionally, the GFCI protected US outlets feature a two-piece construction, providing a nominal current rating of 20 A at 125 V With an automatic self-testing function every 3 seconds and a user-friendly status indicator showcased by a red LED, this insert plate ensures safety and reliability in any setting.

Features and Benefits:

•Complies with RoHS without exemptions.

•Automatic self-test every 3 seconds.

•GFCI protection with a trip level sensitivity between 4 mA and 6 mA.

•Allows for a range of flexible conductor connections.

Specifications:
