1963600000 - 8-Core RJ45 IDC Plug for Cat.6A with Locking Lever (Pack of 10)

1963600000 - 8-Core RJ45 IDC Plug for Cat.6A with Locking Lever (Pack of 10)

SKU: 1963600000   Download PDF

Select a Variant:
  • 1963600000 - 8-Core RJ45 IDC Plug for Cat.6A with Locking Lever (Pack of 10)
Qty:
Now $215.46   Web pricing policy
BEFORE   $0.00 Now $215.46 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Experience superior connectivity with this advanced 8-core RJ45 IDC plug, engineered for Category 6A and Class EA applications in accordance with ISO/IEC 11801 2010 standards It supports both EIA/TIA T568 A and B wiring configurations, making it versatile for various setups, including PROFINET applications The plug is equipped with a locking lever and strain relief, both crafted from durable PA UL94-V0 material.

Weighing in at 17831 grams, this plug operates efficiently within a temperature range of -40 °C to 70 °C Its RJ45 connection not only promotes strong field assembly but also features distinct color coding that eases the identification process.

Features and Benefits:

    •Designed for EIA/TIA standards both A and B.

    •Compliant with RoHS without exemptions.

    •Environmental compliance with no SVHC above 0.1 wt%.

    •Zinc diecast housing for durability.

    •Able to support various wire connection cross-sections.

    •Used in PROFINET communication setups.

    •Field-assembled connections.

Specifications:

 Ordering number 1963600000
 GTIN (EAN) 4032248645725
 Operating temperature -40 °C...70 °C
 Fire load 77 kJ
 Halogen No
 Connection 1 RJ45
 Connection 2 IDC
 Insulation cross-section, min. 0.85 mm
 Insulation cross-section, max. 1.6 mm
 Category Cat.6A / Class EA
 Contact material Phosphorus bronze
 Contact surface Gold over nickel
 Connection diameter, solid 0.41...0.64 mm
 Conductor connection cross-section, solid (AWG) AWG 24/1...AWG 22/1
 Conductor connection cross-section, solid 0.13...0.32 mm²
 Connection diameter, flexible 0.48...0.76 mm
 Conductor connection cross-section, flexible (AWG) AWG 26/7...AWG 22/7
 Wire connection cross section, finely stranded, min. 0.141 mm²
 Conductor connection cross-section, flexible 0.14...0.35 mm²
 Protection degree IP20
 Insertion force ≤ 30 N
 Plugging cycles 750
 Ability to reconnect ≥ 10 cycles
 Contact resistance ≤ 20 mΩ
 Current-carrying capacity at 50 °C 1 A
 Dielectric strength, contact / contact ≥ 1000 V AC/DC
 Dielectric strength, contact / shield ≥ 1500 V AC/DC
 Insulation resistance ≥ 500 MΩ
 PoE / PoE+ conforming to IEEE 802.3at
 MICE classification M M1
 MICE classification I I1
 MICE classification C C1
 MICE classification E E3
 Sheath diameter, min. 5.5 mm
 Sheath diameter, max. 8.5 mm
 General standards PROFINET installation instructions
 Certificate no. (cULus) E316369
