1412110000 - Unmanaged 6-Port Fast Ethernet Switch, 50x70x115mm
1412110000 - Unmanaged 6-Port Fast Ethernet Switch, 50x70x115mm
SKU: SKU: 1412110000 Download PDF
- 1412110000 - Unmanaged 6-Port Fast Ethernet Switch, 50x70x115mm
- 1412110000 - Unmanaged 6-Port Fast Ethernet Switch, 50x70x115mm
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Experience reliable connectivity with this unmanaged network switch, featuring 6 RJ45 Fast Ethernet ports and 2 SC Single-mode ports Built to operate in temperatures from -10 °C to 60 °C, it adheres to ROHS compliance for environmental safety Its compact dimensions measure 70 mm in depth, 115 mm in height, and 50 mm in width, weighing only 275 g Additionally, this switch is designed to meet various EMC standards, ensuring it withstands varying environmental conditions with a storage temperature range of -40 °C to 85 °C.
Features and Benefits:
•Housed in a durable aluminum casing, providing IP30 protection.
•Designed for easy DIN rail mounting.
•Includes features for flow control.
•Complies with several industrial standards including EN 55032 and FCC.
•Redundant power supply inputs enhance reliability.
Specifications:
| Operating temperature (max) | 60 °C |
| Operating temperature (min) | -10 °C |
| Storage temperature (max) | 85 °C |
| Storage temperature (min) | -40 °C |
| Transmission rate | 100 Mbps |
| Transceiver type | Singlemode |
| Connector type | SC-Duplex |
| Transmission distance (typical) | 40 km |
| Wavelength TX (min) | 1280 nm |
| Wavelength TX (max) | 1340 nm |
| Receive power (min) | -34 dBm |
| Receive power (max) | -3 dBm |
| Transmission power (min) | -5 dBm |
| Transmission power (max) | 0 dBm |
| Link-budget | 29 dB |
| Power supply voltage (min) | 9.6 V |
| Power supply voltage (max) | 60 V |
| MTBF (minimum hours) | 2428212 h |
| MAC table size | 2 K |
| Packet buffer size | 768 kBit |
| Bandwidth backplane | 1.6 Gbit/s |
