1286920000 - PoE Network Switch with 2x RJ45 and 4x PoE+ Ports
1286920000 - PoE Network Switch with 2x RJ45 and 4x PoE+ Ports
SKU: SKU: 1286920000 Download PDF
- 1286920000 - PoE Network Switch with 2x RJ45 and 4x PoE+ Ports
- 1286920000 - PoE Network Switch with 2x RJ45 and 4x PoE+ Ports
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing this efficient unmanaged PoE network switch, equipped with 2 standard RJ45 10/100 BaseT(X) ports and 4 additional RJ45 10/100 BaseT(X) PoE+ ports for enhanced connectivity Built to endure harsh environments, it boasts an IP30 rating and can function optimally in temperatures ranging from -40 °C to 75 °C This device adheres to RoHS standards and comes with a cULus certification, ensuring safety and environmental compliance.
Weighing in at 375 grams, it also meets various EMC regulations and safety criteria, including UL 508 standards, making it a reliable choice for your networking needs.
Features and Benefits:
•Suitable for environments with temperatures ranging from -40 °C to 75 °C.
•Compatible with PoE standards IEEE 802.3af and IEEE 802.3at.
•Equipped with a total PoE power budget of 62 W at 12-17 V and 120 W at 18-57 V.
•DIP switch for enabling/disabling broadcast storm protection.
•Manufactured from aluminum with IP30 protection degree.
•Easy installation as it can be mounted on a DIN rail.
Specifications:
| Depth | 70 mm |
| Height | 114 mm |
| Width | 50 mm |
| Operating temperature | -40 °C to 75 °C |
| Storage temperature | -40 °C to 85 °C |
| Humidity | 5 to 95 % (non-condensing) |
| PoE output current (IEEE 802.3af) | 350 mA |
| PoE output current (IEEE 802.3at) | 600 mA |
| PoE output power (IEEE 802.3af) | 15.4 W |
| PoE output power (IEEE 802.3at) | 30 W |
| Supply voltage | 12/24/48 V DC |
| MAC table size | 2 K |
| Packet buffer size | 768 kBit |
| Safety standard | UL 508 |
| Protection degree | IP30 |
