1286900000 - Fast Ethernet Media Converter with SC Port, -40°C to 75°C
1286900000 - Fast Ethernet Media Converter with SC Port, -40°C to 75°C
SKU: SKU: 1286900000 Download PDF
- 1286900000 - Fast Ethernet Media Converter with SC Port, -40°C to 75°C
- 1286900000 - Fast Ethernet Media Converter with SC Port, -40°C to 75°C
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing a versatile media converter tailored for Fast Ethernet, featuring one RJ45 port alongside one SC Single-mode port This unit operates efficiently in extreme temperatures, from -40 °C to 75 °C, making it suitable for various environments It adheres to ROHS standards and boasts UL certifications E230683 and E223527, ensuring reliability and safety in its performance.
Features and Benefits:
•Effective temperature range of -40 °C to 75 °C.
•Connects singlemode fiber.
•Fast Ethernet speed.
•Durable metal housing with IP30 protection.
•Compact dimensions for easy installation.
Specifications:
| Order No. | 1286900000 |
| Depth | 105 mm |
| Height | 135 mm |
| Width | 53.6 mm |
| Storage temperature | -40 °C to 85 °C |
| Operating temperature | -40 °C to 75 °C |
| Transmission rate | 100 Mbps |
| Transceiver type | Singlemode |
| Connector type | SC-Duplex |
| Transmission distance | 40 km |
| Wavelength | 1,310 nm |
| Receive power | -34 dBm to -3 dBm |
| Transmission power | -5 dBm to 0 dBm |
| Link-budget | 29 dB |
| Current consumption | {'12 V': '0.32 A', '24 V': '0.16 A'} |
| Power supply | 24 V DC with redundant inputs |
| MTBF | 401,000 hours |
| Protection degree | IP30 |
| Type of mounting | DIN rail |
