1286550000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, Wide Temp Range
1286550000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, Wide Temp Range
SKU: SKU: 1286550000 Download PDF
- 1286550000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, Wide Temp Range
- 1286550000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, Wide Temp Range
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Experience reliable connectivity with this unmanaged network switch featuring 4 RJ45 ports and 1 SC multimode port, fully supporting Fast Ethernet Built to endure harsh conditions, it functions seamlessly in temperatures ranging from -40 °C to 75 °C and adheres to IP30 standards Certified with ROHS and cULus approvals, this switch guarantees dependable performance across diverse environments.
Features and Benefits:
•Operating temperature from -40 °C to 75 °C.
•Humidity tolerance of 5 to 95% (non-condensing).
•Lightweight aluminum housing with IP30 protection.
•Unmanaged switch suitable for straightforward network applications.
•Power supply with two redundant inputs.
Specifications:
| Number of Ports | 4 x RJ45, 1 * SC Multi-mode |
| Dimensions | 70 mm (D) x 115 mm (H) x 30 mm (W) |
| Net Weight | 175 g |
| Storage Temperature | -40 °C to 85 °C |
| Operating Temperature | -40 °C to 75 °C |
| EMC Standards | EN 55032, EN 55035, FCC Part 15 Subpart B Class A |
| Supply Voltage | 12/24/48 V DC |
| Current Consumption | 0.11 A at 24 V |
| MTBF | 3,500,324 hours |
| Protection Degree | IP30 |
| Bandwidth Backplane | 1 Gbit/s |
| MAC Table Size | 2 K |
| Packet Buffer Size | 768 kBit |
| Priority Queues | 4 |
| Fibre-optic Ports | 100BaseFX ports (SC connector) |
| Transmission Rate | 100 Mbps |
| Transceiver Type | Multimode |
