1286540000 - Fast Ethernet Switch with 4 RJ45 Ports, IP30 Rated
1286540000 - Fast Ethernet Switch with 4 RJ45 Ports, IP30 Rated
SKU: SKU: 1286540000 Download PDF
- 1286540000 - Fast Ethernet Switch with 4 RJ45 Ports, IP30 Rated
- 1286540000 - Fast Ethernet Switch with 4 RJ45 Ports, IP30 Rated
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Experience reliable connectivity with this unmanaged switch tailored for Fast Ethernet networks Featuring four RJ45 ports and a single ST multi-mode port, it is engineered to perform well in demanding conditions with an operational temperature range of -40°C to 75°C The unit is built to last, offering an IP30 protection rating to safeguard against dust and debris Additionally, it meets RoHS compliance standards and carries UL certifications, ensuring safety and quality for your networking needs.
Features and Benefits:
•Unmanaged network switch with Fast Ethernet capabilities.
•Designed for industrial applications with an operating temperature of -40°C to 75°C.
•Complies with EMC standards.
•UL/cUL classified for certain explosive risk zones.
•Shock and vibration resistant according to IEC standards.
•DIP switch for broadcast storm protection enable/disable.
Specifications:
| Operating temperature | -40 °C to 75 °C |
| Storage temperature | -40 °C to 85 °C |
| Dimensions (W x H x D) | 30 mm x 115 mm x 70 mm |
| Bandwidth backplane | 1 Gbit/s |
| MAC table size | 2 K |
| Packet buffer size | 768 kBit |
| Protection degree | IP30 |
| Voltage supply range | 9.6 V to 60 V |
| Current consumption | 0.11 A at 24 V |
| Supply voltage | 12/24/48 V DC |
| MTBF | 3,293,423 hours at 25 °C |
