1286530000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, -40°C to 75°C
1286530000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, -40°C to 75°C
SKU: SKU: 1286530000 Download PDF
- 1286530000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, -40°C to 75°C
- 1286530000 - 4-Port Unmanaged Fast Ethernet Switch, IP30, -40°C to 75°C
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Enhance your network capabilities with this unmanaged switch that features four RJ45 ports and a SC Single-mode port for Fast Ethernet support Engineered for IP30 operation, it performs effectively in extreme temperatures ranging from -40 °C to 75 °C This model is certified by cULus, carrying certificate numbers E141197 and E223527, and meets RoHS compliance standards Its compact dimensions of 70 mm (depth) x 115 mm (height) x 30 mm (width) and a lightweight design at 175 g make it a versatile addition to your networking setup.
Features and Benefits:
•Environmental compliance with RoHS exemption status.
•Storage temperature ranges from -40 °C to 85 °C.
•Operating in humid environments with 5 to 95% non-condensing humidity.
•Supports 100 Mbps transmission rate with single-mode transceiver type.
•Robust shock and vibration resistance according to IEC standards.
•Reverse polarity protection feature available.
Specifications:
| Operating temperature (min) | -40 °C |
| Operating temperature (max) | 75 °C |
| Storage temperature (min) | -40 °C |
| Storage temperature (max) | 85 °C |
| EMC standards | EN 55032, EN 55035, FCC Part 15 Subpart B Class A |
| Fibre-optic ports | 100BaseFX ports (SC connector) |
| Number of ports | 4 x RJ45, 1 * SC Single-mode |
| MAC table size | 1 K |
| Supply voltage | 12/24/48 V DC |
| Protection degree | IP30 |
| Housing main material | Aluminium |
| Bandwidth backplane | 1 Gbit/s |
| Packet buffer size | 448 kBit |
| Current consumption | 0.11 A at 24 V |
| Voltage supply range (min) | 9.6 V |
| Voltage supply range (max) | 60 V |
