1241020000 - Managed Fast Ethernet Switch, 6 RJ45 & 2 SC Ports
1241020000 - Managed Fast Ethernet Switch, 6 RJ45 & 2 SC Ports
SKU: SKU: 1241020000 Download PDF
- 1241020000 - Managed Fast Ethernet Switch, 6 RJ45 & 2 SC Ports
- 1241020000 - Managed Fast Ethernet Switch, 6 RJ45 & 2 SC Ports
Couldn't load pickup availability

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the IE-SW-VL08MT-6TX-2SCS, a sophisticated managed network switch optimized for Fast Ethernet connections It boasts 6 RJ45 ports along with 2 single-mode SC fiber optic ports, delivering reliable network management With an IP30 rating, this switch is engineered to withstand harsh conditions, functioning in temperatures ranging from -40 °C to 75 °C Compliant with ROHS standards and UL certified, it combines durability with regulatory adherence, making it a perfect choice for environments that face extreme temperatures.
Its sturdy construction and compliance ensure it performs dependably, even in the most challenging applications.
Features and Benefits:
•Compliant with ROHS and UL certifications.
•Operating temperature ranges from -40 °C to 75 °C.
•Supports redundancy and overload protection.
•Equipped with various management features like SNMP and Telnet.
•Designed for industrial environments with IP30 protection.
Specifications:
| Depth | 105 mm |
| Height | 135 mm |
| Width | 53.6 mm |
| Net weight | 890 g |
| Storage temperature | -40 °C...85 °C |
| Humidity | 5 to 95 % (non-condensing) |
| Transmission rate | 100 Mbps |
| Transceiver type | Singlemode |
| Operating temperature, max | 75 °C |
| Voltage supply range | 12/24/48 V DC |
| Protection degree | IP30 |
| Speed | Fast Ethernet |
| Type of mounting | DIN rail |
