Description:
Introducing the ENERGY ANALYSER D550-24, a sophisticated device engineered for comprehensive energy measurement and analysis Encased in a sturdy plastic housing, this analyser complies with RoHS standards and operates efficiently within a temperature range of -10 °C to 55 °C With its ability to measure currents up to 5000 A and deliver precise current and voltage readings, it guarantees accuracy in monitoring.
The D550-24 supports various communication protocols including Modbus RTU and Ethernet, making it adaptable for diverse applications Additionally, its substantial data storage capacity allows for effective long-term energy monitoring.
Features and Benefits:
•Plastic housing material.
•Compliant with RoHS and other environmental requirements.
•Reports on voltage quality with harmonics and distortion factors.
•Four-wire system support for accurate measurements.
•Integrated logic for advanced functions.
•LCD display for monitoring.
•Communication interface includes RS232, RS485, and Ethernet.
•Up to 128 MB memory for data storage.
Specifications:
| Depth | 46 mm |
| Height | 90 mm |
| Width | 107.5 mm |
| Storage temperature | -25 °C...70 °C |
| Operating temperature | -10 °C...55 °C |
| Humidity at operating temperature | 5…95 % RH |
| Current-measuring channels | 4 |
| Max. current | 5000 A |
| Rated current | 1 / 5 A |
| Distortion factor THD-I in % | Yes |
| Measuring accuracy for current | 0.25 % |
| Measuring voltage input | Yes |
| Distortion factor THD-U in % | Yes |
| Measurement range, voltage L-L, AC | 480 V |
| Measurement range, voltage L-N, AC | 277 V |
| Measuring accuracy for voltage | 0.2 % |
| Quadrants | 4 |
| Protection degree | IP20 |
| Type of mounting | DIN rail |
| Input frequency | <20 Hz |
| Supply voltage | 20 ... 50 V AC ±10%, 20 ... 70 V DC ±10% |
| Continuous measurements | Yes |
| Measurement result per second | 5 ms |
| Operating-hours counter | Yes |
| Weekly time switch | Yes |
| Bimetal function | Yes |
| Peak load optimisation | Yes |
| Sequence-of-events recorder function | Yes |
| Surge voltage category | 300 V CAT III |
