2727220000 - OMNIMATE Clamping Yoke Connector, 32A, 0.05-6mm² Compatibility (Pack of 180)
2727220000 - OMNIMATE Clamping Yoke Connector, 32A, 0.05-6mm² Compatibility (Pack of 180)
SKU: SKU: 2727220000 Download PDF
- 2727220000 - OMNIMATE Clamping Yoke Connector, 32A, 0.05-6mm² Compatibility (Pack of 180)
- 2727220000 - OMNIMATE Clamping Yoke Connector, 32A, 0.05-6mm² Compatibility (Pack of 180)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the TPS 762/02/90 50SN GN BX, a fully certified component that meets all necessary standards including RoHS compliance and UL certification (E175455) This item is part of the OMNIMATE basic series and features a clamping yoke connection method It supports a wide variety of wires, accommodating sizes from 005 mm² to 6 mm² in cross-section This reliable component boasts a maximum current rating of 32 A and a voltage capacity of 1000 V per IEC standards, with UL ratings of 20 A at 300 V, ensuring it is versatile and dependable for your electrical needs.
Features and Benefits:
•Compliant with RoHS and has a UL certificate.
•Supports clamping yoke connection method for easy installation.
•Has a rated current of 32 A and voltage of 1000 V.
•Suitable for various wire sizes from AWG 30 to AWG 10.
Specifications:
| Order No. | 2727220000 |
| IEC Rating | 1000 V / 32 A / 0.05 - 6 mm² |
| UL Rating | 300 V / 20 A / AWG 30 - AWG 10 |
| Dimensions (mm) | {'Depth': '12.5 mm', 'Height': '21.5 mm', 'Width': '7.62 mm'} |
| Solder Pin Length | 5 mm |
| Pitch | 7.62 mm |
| Number of Poles | 2 |
| Clamping Torque | 0.5 - 0.55 Nm |
| Storage Temperature | -40 °C to 70 °C |
| Operating Temperature | -40 °C to 105 °C |
| Material | {'Insulating Material': 'PA', 'Contact Material': 'Cu-alloy'} |
| Flammability Rating | V-0 |
| Stripping Length | 7 mm |
