2651260000 - 14-Pole PCB Terminal Block with 135° Conductor Outlet (Pack of 42)
2651260000 - 14-Pole PCB Terminal Block with 135° Conductor Outlet (Pack of 42)
SKU: SKU: 2651260000 Download PDF
- 2651260000 - 14-Pole PCB Terminal Block with 135° Conductor Outlet (Pack of 42)
- 2651260000 - 14-Pole PCB Terminal Block with 135° Conductor Outlet (Pack of 42)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the TSS 500/14/135 33SN GN BX terminal block, engineered for optimal connectivity Designed for PCB installations, this component includes a clamping yoke connection with a THT solder option and features a conductor outlet angle of 135° It accommodates 14 poles with a 5 mm pitch, utilizing a secure screw connection that meets specific torque specifications for reliable performance Crafted from a pale green insulating material, this product adheres to ROHS standards, ensuring it’s safe and compliant for various applications.
Features and Benefits:
•Compliant with RoHS.
•Clamping yoke connection method.
•Low flammability rating of UL 94 V-0.
•Easily accommodates various conductor sizes up to 2.5 mm².
•Supports a wide range of conductor types.
Specifications:
| IEC Rated Voltage | 630 V |
| IEC Rated Current | 20 A |
| UL Rated Voltage | 300 V |
| Wire Connection Cross Section (min) | AWG 30 |
| Wire Connection Cross Section (max) | AWG 12 |
| Number of Poles | 14 |
| Solder Pin Length | 3.3 mm |
| Protection Degree | IP20 |
| Storage Temperature Min | -40 °C |
| Operating Temperature Max | 105 °C |
| Tightening Torque Min | 0.5 Nm |
| Tightening Torque Max | 0.55 Nm |
| Insulating Material | PA |
