Description:
Introducing the OMNIMATE basic series component, featuring a reliable clamping yoke connection with a solder pin length of 33 mm This versatile product accommodates a total of 13 poles and is compatible with wire sizes ranging from AWG 30 to AWG 12 Built for demanding environments, it offers dependable performance under its operational specifications With a maximum operating temperature of 105 °C and a minimum storage temperature of -40 °C, this component is designed to withstand a range of conditions.
It complies with RoHS standards and comes with multiple certifications, making it an excellent choice for various applications.
Features and Benefits:
•Compliant with RoHS and has a cURus certificate.
•Clamping yoke connection method for easy installation.
•Pale green color matching RAL 6021.
•Insulating material that meets UL 94 flammability rating V-0.
Specifications:
| IEC Voltage Rating | 630 V / 20 A / 0.2 - 2.5 mm² |
| UL Voltage Rating | 300 V / 20 A / AWG 30 - AWG 12 |
| Conductor Outlet Direction | 135° |
| Pitch | 5 mm (0.197 inches) |
| Number of Poles | 13 |
| Solder Pin Length | 3.3 mm |
| Insulating Material | PA |
| Protection Degree | IP20 |
| Tightening Torque Min | 0.5 Nm |
| Tightening Torque Max | 0.55 Nm |
| Wire Connection Cross Section Min | 0.2 mm² |
| Wire Connection Cross Section Max | 2.5 mm² |
| Rated Current | 20 A |
| Rated Voltage | 300 V |
