2650990000 - 6-Pole 15A Connector, 0.2-2.5mm², 90° Outlet, IP20 (Pack of 160)

Description:

Introducing the TMS 500/06/90 30SN GN BX connector, expertly crafted for versatile wire connections with essential specifications This connector operates efficiently at 15 A with a voltage rating of 300 V for UL and 15 A at 320 V per IEC guidelines It accommodates wire sizes ranging from 02 mm² to 25 mm², compatible with AWG 30 to AWG 12 Featuring a clamping yoke connection for secure setup, it offers a 90° outlet direction for optimal space management.

Made from durable insulating PA material and compliant with RoHS regulations, this connector boasts six poles arranged in a single row, providing IP20 protection for reliable use Its robust design allows it to function effectively across a broad temperature spectrum, making it suitable for diverse environments It’s specifically designed for hassle-free installation, accepting designated wire types with accurate cross-section requirements.

Features and Benefits:

•RoHS compliant with exemption.

•IP20 protection degree.

•Clamping yoke connection for secure wire attachment.

•Suitable for various wire types including solid and flexible connections.

•Compatible only with OMNIMATE basic products.

•Optimized for use with THT solder connections.

•Use in general electronic connections.

•Suitable for connecting wires on various PCBs.

Specifications:
