2651790000 - OMNIMATE 10-Pole THT Component with Clamping Yoke Connection (Pack of 72)

Description:

Introducing the TPS 500/10/90 35SN GN BX component, designed with quality and compliance in mind This product adheres to RoHS standards and holds the UL File Number E60693, making it a reliable choice for various applications It meets IEC specifications for 320 V and 15 A, supporting wire connection sizes from 02 to 4 mm² The UL rating allows for 300 V and 15 A capacity, accommodating AWG wire sizes from 30 to 12.

Each order is delivered in a box of 72 units, part of the esteemed OMNIMATE basic series The connection features a clamping yoke for secure wire attachment and utilizes THT solder connections for straightforward PCB mounting With 10 poles, each equipped with 1 solder pin, this component offers versatile conductor options that can exit at a 90-degree angle To ensure optimal functionality, the component requires a tightly controlled installation torque, ranging from a minimum of 0.

5 Nm to a maximum of 055 Nm Rated IP20, this durable product is constructed from pale green PA insulating material, combining both aesthetic appeal and safety in design.

Features and Benefits:

•RoHS compliant with exemption.

•Suitable for both solid and flexible connection options.

•Clamping yoke connection facilitates easy wire attachment.

•Compatible exclusively with OMNIMATE basic products.

Specifications:
