2651430000 - 5.08mm Pitch 12-Pole Terminal Block with Clamping Yoke (Pack of 80)

Description:

Introducing the TMS 508/12/90 30SN GN BX terminal block, expertly crafted for seamless PCB integration with its reliable clamp yoke connection Engineered for through-hole mount soldering, this component features a compact 508 mm pitch design and includes 12 poles, each equipped with a 3 mm solder pin length Constructed from PA insulation material, it complies with UL 94 V-0 standards for excellent fire resistance.

This versatile terminal block can handle wire cross-sections ranging from 02 mm² to 25 mm², making it an ideal choice for a variety of electronic applications Additionally, it is designed to operate effectively across a wide temperature range, ensuring dependable functionality in different settings.

Features and Benefits:

•Compliant with RoHS and certain exemptions.

•Single connection method with a clamping yoke.

•Solder pin dimensions of 0.7 x 0.9 mm.

•IP20 protection degree for dust protection.

•Suitable for long-term storage under specific conditions.

Specifications:
